500 W non-networked Class-D amplifier with 4 channels
Features
Specifications
| Total System Power | 500 W |
|---|---|
| Output Power @ 4/8Ω | 4 x 125 W |
| Output Power @ 70/100V* | 4 x 125 W |
| Powershare (up to) Across all channels** | 2 x 250 W |
| Power Consumption | 150W |
| Dimensions | 44.5 x 220 x 337 mm |
| Weight | 2.4 kg (5.3 lbs) |
| Output Circuitry | UMAC™ Class D – full bandwidth PWM modulator with ultra-low distortion |
| Output Voltage | 45Vrms (S.E) – 70/100V (Hi-Z) |
| Signal To Noise-Ratio | > 100 dB (A-weighted, 20 Hz – 20 kHz, 8 Ω load) |
| THD+N (typical) | < 0.05 % (20 Hz – 20 kHz, 8 Ω load, 3 dB below rated power) |
| Frequency Response | 20 Hz – 20 kHz (+0/-0.25 dB (8 Ω load, 3 dB below rated power) |
| Protection Circuits | Short circuit protection, DC protection, under voltage protection, temperature protection, overload protection |
| Power Supply | UREC™ universal mains switch mode power supply with Power Factor Correction (PFC) |
| Operating Voltage/Frequency. | Universal Mains, 100-240V, 50-60Hz |
| Standby Consumption | < 0.5 W (Energy Star & ErP 1275/2008/EC compliant) |
| Power Ratings | 1% THD @ 120VAC and 230VAC |
Description
With full rack support and adaptable desk and wall mount brackets, the PowerZone™ series offers unparalleled installation versatility in a compact form factor that seamlessly fits into spaces where other amplifiers may fall short.
Like all PowerZone products from Blaze Audio, these amplifiers come with a 5- year warranty.
With full rack support and adaptable desk and wall mount brackets, the PowerZone™ series offers unparalleled installation versatility in a compact form factor that seamlessly fits into spaces where other amplifiers may fall short.
Like all PowerZone products from Blaze Audio, these amplifiers come with a 5- year warranty.
