CBL523

SKU N/A Category Tags ,

Passive, 2-way Constant Beamwidth Loudspeaker

Features

  • Two x 5” custom low-frequency drivers.
  • Three x 2” mid-high frequency drivers.
  • 160° x 55°* Constant Beamwidth pattern.
  • 119 dB maximum SPL.
  • Symmetrical and compact trapezoidal design.
  • Powder coated steel grille with a high transmission ratio.
  • Tuned with a passive crossover and integration with Blaze Audio.
*(Average beamwidth, 500 Hz – 5 kHz)

Specifications

Additional information

Frequency Response (-3dB)*

71 Hz – 18 kHz

Frequency Range (-10 dB)*

55 Hz – 18 kHz

Horizontal Nominal Dispersion (-6 dB)

160°

Vertical Nominal Dispersion (-6 dB)

55° (Average beamwidth, 500Hz – 5kHz)

Long Term Power Handling (Full Range)**

160 W

Impedance

4 ohms

Pressure Sensitivity @ 1 W / 1m)***

91 dB

Max SPL @ 1 W / 1 m

119 dB

Colour

Black, White

Description

The ultra-compact and innovatively designed CBL523 is a perfect fit where on-wall distributed audio is needed. The 20.5 x 35 cm (8″ x 14″) enclosure features two 5” low-frequency drivers complemented by a vertical constant directivity array of three 2” high-frequency drivers, delivering 119 dB of maximum SPL in a focused 160° (horizontal) x 55°* (vertical) pattern.

The CBL523 has versatile mounting options with custom-designed hardware, as well as the ability to stack and suspend two units together for increased SPL and an increased vertical pattern.
