BL118iSS

SKU FGM-888-010 Category Loudspeakers Tags cca10, Product Template 2025, us

High-output sub-bass companion subwoofer housed in a tour-grade enclosure

Features

2500 W of stunning low-end response.
Symmetrical dispersion pattern.
Designed to meet the demand for an extremely high SPL sub-bass loudspeaker system, with components carefully selected solely for their performance.
Utilizes a direct radiating 18-inch, 2000 W cone driver in a tuned enclosure, which provides maximum output with minimal distortion and smooth extended low frequency response.
Tour-tested 21-ply Baltic Birch highly braced enclosure and 24 mm thick baffle board construction.
Configurable as in cardioid, or end-fire arrays.
Fully integrates with Blaze Audio’s PowerZone™ Connect amplifiers (3004 or higher).

Specifications

Additional information

Frequency Response (-3dB)1	26 Hz – 150 Hz
Frequency Range (-10 dB)1	18 Hz – 150 Hz
Recommended High-Pass Filter	20 Hz – with minimum 24 dB / octave (4th order) Butterworth slope
Nominal Directivity (-6 dB)	Omni or cardioid
Recommended Crossover Frequency	90 Hz (acoustic, active, external DSP)
RMS Handeling Capcity**	LF: 2500 W
Max System SPL (@ 1W/1m)	136 db (Blaze Audio preset)
Transducer Components	LF: 18” (457.2 mm) x 1
Transducer Nominal Impedance	LF = 4 ohms
